SICK microScan3 Core I/O Mounting Instructions

All rights reserved. Subject to change without notice.
1 About this document
This document applies to the microScan3 safety laser scanner and the associated sys‐
t
em plug with the following part numbers:
Safety laser scanner Safety laser scanner without
s
ystem plug
System plug
•
1075842
•
1075843
•
1089492
•
1067360
•
1067875
•
1089325
•
2073156
Symbols and document conventions
A, B References to the figures at the end of this document are indi‐
c
ated by a black background.
2 Safety information
DANGER
H
azard due to lack of effectiveness of the protective device
In the case of non-compliance, it is possible that the dangerous state of the machine
may not be stopped or not stopped in a timely manner.
b
Please observe the safety notes provided.
The safety laser scanner is no
t suitable for the following applications, among others:
•
Outdoors
•
Underwater
•
In explosive environments
For more information about how to work with the protective device, refer to the machin‐
ery documentation or the operating instructions for the protective device. You can call
up the EU declaration of conformity and the current operating instructions for the pro‐
tective device by entering the part number in the search field at www.sick.com (part
number: see the type label entry in the “Ident. no.” field).
3 Device overview
Overview:
A
1
Optics cover
2
Display
3
Keypad
4
USB port
5
Status LEDs
6
Additional LEDs for ON state and OFF state
7
Safety laser scanner without system plug
8
System plug
The USB connection (USB 2.0 Mini-B, female connector) may only be used temporarily
and onl
y for configuration and diagnostics.
MOUNTING INSTRUCTIONS
8017779/ZYM7/2018-05-15 | SICK M O U N T I N G I N S T R U C T I O N S | microScan3 Core I/O
9
Subject to change without notice
