SICK MSL
8 007 653/09-04-01 Technical Description • MSL © SICK AG • Safety Systems • Germany • All rights reserved
Contents
Approvals
EU Europe
EU-sample test by:
TÜV Rheinland
Am Grauen Stein
D-51105 Köln
Test number BB 9511541 01
E 9512741 E 01
6 Operating modes 17
6.1 Self configuration 17
6.2 Restart inhibit 17
6.3 External device
monitoring 17
6.4 Muting with additional
MSM module 17
7 Electrical
installation 18
7.1 General 18
7.2 Sender unit 19
7.2.1 MCC-test input 19
7.2.2 Scanning range of the
sender unit 19
7.3 Receiver unit 20
7.3.1 Switching outputs 20
7.3.2 Output: Contamination
warning (OWS) 20
7.3.3 Input: External Device
Monitoring (EDM) 21
7.3.4 Input: Restart switch (RES) 21
7.4 Example circuits 22
8 Connector diagrams 23
9 Diagnosis elements 26
10 Technical
specifications 27
11 Dimensional
diagrams 29
12 MSL selection table 30
13 Accessory selection
table 32
14 Checklist 34
1 General 3
1.1 Features 3
2 Safety instructions 4
2.1 Areas of use of the device 4
2.2 Intended use of the device 5
2.3 General safety instructions
and precautions 5
2.4 Safety instructions 6
2.4.1 Pre-commissioning tests 6
2.4.2 Regular testing of the
safety device by experts 6
2.4.3 Daily testing 6
3 Function 7
3.1 Status indicator 7
3.2 Diagnosis elements 7
3.3 Diagnosis aids 7
4 Applications and
application
requirements 8
4.1 Applications 8
4.2 Application requirements 8
4.3 Corner mirrors and
columns 9
5 Mechanical
installation 10
5.1 General 10
5.2 Safety distance to point of
danger, determination of
safety distance 10
5.2.1 General formula for the
safety distance according
to EN 999 10
5.2.2 Safety distance for multi-
beam access control
according to EN 999 10
5.2.3 Safety gap for horizontal
multi-beam danger area
guarding according to
EN 999 11
5.3 Distance from reflective
surfaces 12
5.4 Multiple safeguarding 12
5.5 Mechanical fixing 13
5.6 Mounting the mirror
columns 14
5.7 Corner mirror PSK 45 16
Caution sign
Non-observance can
cause dangerous
situations
Application hint
Technical hints for
correct and efficient
application
certified by DQS according to
DIN EN ISO 9001 Reg.-No. 462-03
QUALITY SYSTEM
