SICK MSL
8 007 653/09-04-01 Technical Description • MSL © SICK AG • Safety Systems • Germany • All rights reserved
5.7 Corner mirror The PSK 45 corner mirror ( fig. 16 )
is not suitable for column mount-
ing. The part number 5 306 053
contains an assembly kit.
The PSZ corner mirror is espacially
suited to the MSLZ as a passive side
(
fig. 17 ). The mirrors are housed in
the MSLZ housing profile. The PSZ
offers the following advantages:
‡ Mirror does not have to be
cleaned (IP 65 enclosure)
‡ Easy to adjust
‡ Tolerant to small adjustment
errors
Fig. 17: Dimensions of the PSZ corner mirror
80
96,5
8,5
80
63
40
8,5
8,5
69,5
146,5
40,5
45˚
76
Ø 5,5
Fig. 16: Dimensions of the PSK 45 corner mirror
55
52
10,5
2,2
3,5
6,7
14
6
Abmessung der Schiebemutternut
A
F
B
20
E
Dimensions of the slider nut
Centre of the mirror
surface
Dimensions in mm
Dimensions in mm
ABCDEF
PSZ 01-1501 500 668 508 80 81 87
PSZ 01-1401 400 581 421 80 101 80
