SICK nanoScan3 Mounting Instructions

All rights reserved. Subject to change without notice.
1 About this document
This document applies to the nanoScan3 safety laser scanner and the associated sys‐
t
em plug with the following part numbers:
Safety laser scanners System plug
1100333
•
2105106
•
2104949
1100334
•
2105107
•
2104860
•
2105109
•
2105108
Symbols and document conventions
A, B References to the figures at the end of this document are indi‐
c
ated by a black background.
2 Safety information
DANGER
H
azard due to lack of effectiveness of the protective device
In the case of non-compliance, it is possible that the dangerous state of the machine
may not be stopped or not stopped in a timely manner.
b
Please observe the safety notes provided.
For more information about how to work with the protective device, refer to the machin‐
er
y documentation or the operating instructions for the protective device. You can call
up the EU declaration of conformity and the current operating instructions for the pro‐
tective device by entering the part number in the search field at www.sick.com (part
number: see the type label entry in the “Ident. no.” field).
NOTICE
Enc
losure rating IP65 only applies if the optics cover and the system plug are mounted
and the USB connection is closed with the protective cover.
NOTICE
If t
he system plug is mounted with excessive force, the contacts can break or bend.
b
Plug in the system plug carefully.
b
Do not force it.
3 Device overview
Overview:
A
1
LED ON status
2
LED OFF status
3
LED restart interlock/warning field
4
Optics cover
5
USB connection
6
Display
MOUNTING INSTRUCTIONS
8024612/2019-10-28 | SICK M O U N T I N G I N S T R U C T I O N S | nanoScan3
13
Subject to change without notice
