SICK OD5000 Series - Measurement; Selecting Default Settings

Bit Comments
31 ON if laser switched on
30 ON if memory full
29 ON if precision timesync is working
28 ON for alarm status
27 (not used)
26 (not used)
25 Input terminal usage
24 (not used)
23 (not used)
22 (not used)
21 (not used)
20 Channel D control input/output
19 Channel C control input/output
18 Channel B control input/output
17 Channel A control input/output
16 (not used)
15 (not used)
14 (not used)
13 (not used)
12 (not used)
11 Channel A HI output
10 Channel A GO output
9 Channel A LO output
8 (not used)
7 (not used)
6 Channel A hold ON
5 Channel A zero set ON
4 (not used)
3 ON if measurement not possible for channel 1
2 Channel A control input/output status (ON/OFF)
1 (Normally ON)
7.4.3 Measurement
7.4.3.1 Selecting default settings
Table 30: Command list for default settings
Access Com‐
mand
Name Parameter Comments
R/W 0x0CA0 Mounting 0x00: Diffuse
0x01: Specular
R/W 0x0CA8 Synchronization mode 0x00: None
0x01: Synchronous
0x02: Anti-interference 1
0x03: Anti-interference 2
