SICK PBS Series User Manual

8013154/U275/2010/02/01 ©SICKAG•Germany•Allrightsreserved•Subjecttochangewithoutnotice 43
Operating Instructions PBS
SICK-specic
Index
(dezimal)
Name Format Access Range Remark
250
Display-
Rotation
8 Bit
enumeration
R/W
0 = Regular
(normal)
1 = UpsideDown
(gedreht)
Enables electronic rotation of display by 180°.
251
Display
Mode
8 Bit
Enumeration
R/W
0=Act:Displayvalue
1=Hi:DisplayHI
2=Lo:DisplayLO
3 = SP1 (FH1)
Display SP1 or FH1
4 = RP1 (FL1)
Display RP1 or FL1
5 = SP2 (FH2)
Display SP2 or FH2
6 = RP2 (FL2)
Display RP2 or FL2
7 = Off no Display
Speciesthestandarddisplay.
Act corresponds to the actual system pressure,
HI corresponds to the maximum system pressure,
LO corresponds to the minimum system pressure.
SP1 / SP2 correspond to the switching points 1 / 2
RP1 / RP2 correspond to the reset points 1 / 2
FH1 / FH2 correspond to the upper window limits 1 / 2
FL1 / FL2 correspond to the lower window limits 1 / 2
Forcongurationswithonlyoneswitchingoutputthevalues5and6are
notused.Inthiscase,thedeactivationofthedisplayistriggeredbythe
value7=Off.
252
Display-
Pass-
word
16 Bit
unsigned
R/W 0…9999
Password that is needed to adjust the pressure switch locally. If the
password is set to 0, the user is not prompted for a password.
253 LOCK
8 Bit
Enumeration
R/W
0 = Unlocked
1 = Locked
Locks the menu such that the programming mode can not be entered.
System Commands
Index Value Name Remark
2 130 Restore Factory Settings Resets all SPDUs to factory settings.
2 163 Key Lock Locks the display against local parameter adjustments (SPDU LOCK is set to 1).
2 164 Key Unlock Unlocks the display for local parameter adjustments (SPDU LOCK is set to 0).
2 176
Reset HI and LO
values
Resetsthevalueofthehighestappliedpressure(HI)to0andresetsthevalueofthelowestapplied
pressure(LO)tothevalueoftheupperendofthemeasuringrange.
2 177 Set pressure to zero
Setstheoutputsignaltoitszerovalue.
This function is only applied when the resulting zero offset to the factory-set zero point is less than +3%
of the span.
7. Starting, operation
7. Starting, operation
