Safety laser scanners
You can nd more detailed data in the operating instructions. Download at www.mysick.com
General data
1, (21 CFR 1040.10 and 1040.11, IEC 60825-1)
IP 65 (EN 60529)
II (EN 50178)
Type Type 3 (IEC/EN 61496-3)
Safety integrity level SIL2 (IEC 61508), SILCL2 (EN 62061)
Category Category 3 (EN ISO 13849)
Performance level PL d (EN ISO 13849)
PFHd (mean probability of a
dangerous failure per hour)
8.0 x 10
-8
(EN ISO 13849)
T
M
(Mission Time) 20 years (EN ISO 13849)
–10 °C ... +50 °C
Pulsed laser diode
905 nm
RAL 1021 (yellow)
Aluminum diecast
Polycarbonat
Outside with scratch-resistant coating
With ESD protected conguration memory
155 mm x 185 mm x 160 mm
3.3 kg
Functional data
190°
4 m, 5.5 m, 7 m (depending on type)
1.8 % ... > 1,000 %, reectors
60 ms, 120 ms
1)
30 mm, 40 mm, 50 mm, 70 mm, 150 mm, selectable
0.5°, 0.25°, depending on range and resolution
100 mm
49 m (20 m at 20 % reectivity)
49 m
2 ... 16, congurable via CDS
2 s ... 60 s, congurable
1)
Depending on basic response time and multiple sampling.
