Subject to change without notice
Safety laser scanners
Electrical data
Plug-in connection housing with screw, screw-type terminals
24 V DC (16.8 V DC ... 28.8 V DC)
0.8 A (24 V DC), 2.3 A
1)
EDM 1
Restart/Reset 1
Static switching signals 4
Static switching signals (with EFI) 5
2)
Dynamic encoder signals
(incremental encoder)
2
3)
Safety outputs (OSSD) 2 (500 mA)
Diagnostic output 3 x 100 mA
4)
RS-232
Transmission rate 9.6 kBaud, 19.2 kBaud, 38.4 kBaud
RS-422 (≤ 500 kBaud)
Transmission rate ≤ 500 kBaud
Cable length 50 m
Connection conductor cross-section 0.34 mm²
1)
Including maximum output load.
2)
Only in conjunction with a Flexi Soft safety controller or with EFI gateways.
3)
Two of the static switching signals can be used either as dynamic or as static switching signals.
4)
Freely programmable, e.g., warning eld, reset required.
