8.1.1 Situation and function of the LEDs
Device status
Table 11: Device status indicators
Location Designation LED behavior Description
Dev RDY Device booting
Runlevel READY, no errors detected
Runlevel READY, boot process error
Sys RDY
Result
Funct 1
Funct 2
User-defined, configurable using SICK App‐
Space
Remote Remote maintenance app (RSC) not instal‐
led
Remote maintenance app (RSC) installed
but not activated
Remote maintenance app (RSC) installed
and activated
Establishing a connection
Connection establishment successfull
Remote maintenance app (RSC) installed
but no Internet access or app not func‐
tional
OPERATION 8
8023297//2021-06-22 | SICK O P E R A T I N G I N S T R U C T I O N S | SIM2000
31
Subject to change without notice
