SICK UE410-2RO - Page 153

ANA0
Immunity to interference EN 61000-6-2
Emitted interference EN 61000-6-4
Connection type Dual level spring terminals
Wire cross-section Single-wire or fine-stranded wire: 0.2 … 1.5mm²
St
randed wire with ferrule:
a) With plastic ferrule max. 0.75mm²
b) Without plastic ferrule max. 1.5mm²
AWG to UL/CUL: 24 … 16
Power consumption Max. 2W
Power loss
Interfaces
T
able 159: Interfaces ANA0
ANA0
Data interface Internal bus (FLEXBUS+)
Electrical data
T
able 160: Analog inputs (AI) ANA0
ANA0
Number of inputs 2
Type of inputs Electricity
Max. input voltage 30V DC
Max. current 30mA
Current measuring range 4.0 ... 20.0mA
Sampling repetition time 4.0ms
1)
Input area min. 3.5mA
2)
Input area max. 20.5mA
3)
Measuring resistor R
SHUN
T
Between 1+ and 1-
50 W
Between 2+ and 2-
50 W
Measurement accuracy 1% of the scale value (20mA)
Insulation voltage between AI1 and
AI2
0.5kV
Transmission frequency 10.6kHz
Digital resolution 16bit
Value of the lowest bit 0.4μA
1)
Update rate visible at the output (module cycle time); shorter signal pulses at the inputs may not be
de
tected. A maximum of 32 samples per cycle are evaluated.
2)
Threshold below which a sensor fault is assumed. A max. deviation of 1% (full scale value) gives a
tolerance zone of 3.3mA to 3.7mA.
3)
Threshold above which a sensor fault is assumed. A max. deviation of 1% (full scale value) gives a
tolerance zone of 20.3mA to 20.7mA.
