Table 24: Moving average
TOP
A c n t 1
Select the number of measurement repeats.
select and adjust . The display reverts to the
Moving average top menu.
1
Configuring. Mov‐
ing average
1/4/8/16/32/64/128/
256/512/1024/2048
...
2 0 4 8
↓
5.7.5 Extreme value memory
Table 25: Extreme value memory
TOP
h o L d o F F
Select the extreme value memory status.
select and adjust . The display reverts to the
Extreme value memory top menu.
o F F
Extreme value memory
deactivated.
P E A
Maximum value is applied
to the output.
b t t
Minimum value is applied
to the output.
P - P
Difference value between
min. and max. is applied to
the output.
NOTE
Only when the length measurement function is switched on
5.7.6 End analog function configuration
Elt
7.Completing the configuration
Display reverts to the Analog function top menu.
7 Operation
NOTICE
Do not use the sensor without the protective cover.
NOTICE
Do not use the sensor immediately after switching it on (approx. 100ms).
