12 Technical data
WTB26P-xxxxx1 WTB26P-xxxxx4 WTB26I-xxxxx1 WTB26I-xxxxx4
Sensing range max. 30 mm ...
1,600 mm()
1)
30 mm ... 3,000
mm
1)
30 mm ... 2,000
mm
1)
30 mm ... 3,000
mm
1)
Light spot diameter/distance Ø 7 mm (700 mm)
(type)
Ø 7 mm (700 mm)
(type)
Ø 14 mm (1,000
mm)
Ø 14 mm (1,000
mm)
Supply voltage U
B
DC 10 ... 30 V DC 10 ... 30 V DC 10 ... 30 V DC 10 ... 30 V
Ripple ≤ 5 V
SS
≤ 5 V
SS
≤ 5 V
SS
≤ 5 V
SS
Current consumption ≤ 30 mA
2)
< 50 mA
3)
≤ 30 mA
2)
< 50 mA
3)
≤ 30 mA
2)
< 50 mA
3)
≤ 30 mA
2)
< 50 mA
3)
Output current I
max.
≤ 100 mA ≤ 100 mA ≤ 100 mA ≤ 100 mA
Max. response time 500 µs
4)
2.5 ms
4)
500 µs
4)
2.5 ms
4)
Switching frequency 1000 Hz
5)
200 Hz
5)
1000 Hz
5)
200 Hz
5)
Enclosure rating
6)
see table 1:
x4, xH, x5, xI: IP66,
IP67, IP69
7)
x9, xB: IP65
see table 1:
x4, xH, x5, xI: IP66,
IP67, IP69
7)
x9, xB: IP65
see table 1:
x4, xH, x5, xI: IP66,
IP67, IP69
7)
x9, xB: IP65
see table 1:
x4, xH, x5, xI: IP66,
IP67, IP69
7)
x9, xB: IP65
Protection class III III III III
Circuit protection A, B, C, D
8)
A, B, C, D
8)
A, B, C, D
8)
A, B, C, D
8)
Ambient operating temperature –40 °C ... +60 °C
9)
–40 °C ... +60 °C
9)
–40 °C ... +60 °C
9)
–40 °C ... +60 °C
9)
1)
Object with 90 % remission (based on standard white DIN 5033)
2)
16 VDC to 30 VDC, without load
3)
10 VDC to 16 VDC, without load
4)
Signal transit time with resistive load in switching mode. Deviating values possible in COM2 mode.
5)
With a light/dark ratio of 1:1 in switching mode. Deviating values possible in IO-Link mode.
6)
Pursuant to EN 60529
7)
Replaces IP69 K pursuant to ISO 20653: 2013-03
8)
A = U
B
-connections reverse polarity protected
B = inputs and output reverse-polarity protected
C = Interference suppression
D = outputs overcurrent and short-circuit protected
9)
Do not bend cables below 0°C.
