AC MUM0114 rev. 04 - 15 -
SH130
9.1. MOTOR ROTATION INSTRUCTIONS
Before rotang the motor, you must:
- read the “Safety Requirements” chapter.
- disconnect the electrical power supply to the winch.
- Posion the machine vercally so as not to change the alignment of
the motor.
- Remove the pulley unit.
- Unscrew the locknuts so that there is clearance between the shoes
and the drum/ywheel.
- Remove the 4 M10x40 fastening screws that connect the motor unit
to the winch sha.
- Turn the motor unit 180° in a clockwise direcon (to adapt it to your
requirements) unl the holes where the screws were inserted are
lined up with the holes on the winch sha.
- Put the 4 M10x40 screws and washers back in place. Tighten to a
torque of 50 Nm.
① Brake shoe locknut
