Sicor SH130 User Manual

AC MUM0114 rev. 04 - 32 -
SH130
6. Turn the sheave in one direcon unl you feel resistance and set the dial indicator to 0.
7. Turn the sheave in the opposite direcon unl you feel the resistance and read the value on the
dial indicator.
8. If the measured value is equal or exceeds the maximum value in the table 2 keep the elevator out
of service since the gearbox needs to be replaced.
Table 2
Model Distance A Rao Maximum backlash
SH130 100 mm
2/53, 1/52 0,6 mm
3/47, 1/45 0,7 mm
1/43, 2/43 0,8 mm
1/37 0,9 mm
