Midi 201 2904-6 - 2019
Installation
The enclosed steel rings (auto stop rings) are tted in the loca-
tions where the windlass should slow down and then come to a
full stop. Mark in advance; see procedure on the previous page.
Open the stop rings with the keeper ring plier.
Fit the ring over the rope.
Use the plier to pull the stop ring into place with the stop
ring joint overlapping the opening and the ring tted thightly
around the rope.
Force the ends into the rope with the pliers to ensure the stop
ring does not slip on the rope.
A tted stop ring should look like this with closed windings and
the ends secured inside the rope.
Stop ring tted and fastened tightly to the rope.
Fasten the other stop ring in the same manner.
