Swim platform mount
STEP 1: PASS MOUNTING BOLTS THROUGH TOP BACKING PLATE
ON TOP OF SWIM PLATFORM.
Align thruster mounting flange with bolts. Pass each bolt through corresponding
flange hole.
Tighten nuts by wrench onto each bolt.
STEP 2: FEED THRUSTER CABLES THROUGH HULL
Pass the cables through the hull, one per hole.
Seal holes with Sikaflex or equivalent sealant.
