Siemens 3RB22

Technical Data
22 3ZX1012-0RB22-1AA1
English
5 Technical Data
Regulations IEC 60947-4-1 / IEC 60947-5-1 / IEC 60947-8
UL 508, CSA C 22.2
EMC Fast transient bursts acc. to IEC 61000-4-4 2 kV
Electrostatic discharge acc. to IEC 61000-4-2 6/8 kV
Irradiated high-frequency fields acc. to IEC 61000-4-3 10 V/m
Impulse voltage (surge) acc. to IEC 61000-4-5 1/2 kV
Interfer. emission acc. to EN 55011 limit value class: lim. class A
Weight 235 g
Rated control
supply voltage
U
S
Operating range:
AC 50/60 Hz 24 V to 240 V; 0.85 to 1.1 x U
s
DC 24 V to 240 V; 0.85 to 1.1 x U
s
Permissible
ambient
temperature
–25 up to +60 °C
Storage
temperature
–40 to +80 °C
Contact-
equipment
2 x (1 NO + 1 NC)
Galvanic
isolation of the
auxiliary
switches
(floating)
safe isolation at U
i
<= 300 V
Switching
capacity
AC-15: 6 A / 24 V; 6 A / 125 V; 3 A / 250 V
DC-13: 2 A / 24 V; 0,55 A / 60 V; 0,3 A / 125 V;
0.2 A / 250 V
UL/CSA: B300, R300
