The interface module has been tested in accordance with the tests, standards and specifications outlined in
the following table.
Table 15 Tests, standards and specifications
No. Parameter Data Description
1 Vibration test
• 5 Hz ≤ f ≤ 26 Hz, amplitude =
0.75 mm
• 26 Hz ≤ f ≤ 500 Hz, acceleration =
20 m/s
2
à Frequency sweep: 1 octave/min
à 10 freq. sweeps each in x, y, z
ð SN 31205
(IEC 68-2-6-Fc sinusoidal)
(= utilization category: 3M6/1M4)
2 Shock test
• Shock form = half sinusoidal
• Acceleration = 15 g (150 m/s
2
)
• Duration of shock = 11 ms
à 3 shocks in +/- direction in x, y, z
ð SN 31205 (IEC 68-2-27-Ea)
(= utilization category: 3M6/1M4)
3 Drop test 1m high
ð SN 18013
4 Bending and draw-out test
• Screw size: M3
--> tightening torque: 0.5 ... 0.8 Nm
• Wire cross-section: 0.75/1.5/2.5 mm
2
AWG: 18/16/14
• Wire type : rigid, flexible
ð IEC 947-1 (screw connections)
5 Climatic test: - Cold
- Dry heat
- Change of temp.
- Damp heat
• 0 °C/16 h
• 60 °C/16 h
• -25 °C ... 55 °C, 1 °C/min, 2 cycles
• 55 °C, 90 ... 95 %, 12+12h, 2 cycles
ð SN 31205 (IEC 68-2- 1-Ad,
IEC 68-2- 2-Bd,
IEC 68-2-14-Nb,
IEC 68-2-30-Db)
(= utilization category: 3K6/1K6)
6 Pollutant concentration
• SO2 < 0.5 ppm; rel. humidity < 60 %
• H2S < 0.1 ppm; rel. humidity < 60 %
ð SN 31205 (IEC 68-2-60)
(= utilization category: 3C3/1C2)
ð No condensation
7 ESD 8 kV discharge in air
6 kV contact discharge
IEC 1000-4-2 Severity 3
8 Electromagnetic fields 10 V/m
IEC 1000-4-3 Severity 3
9 Burst 2 kV/5 kHz supply voltage
2 kV/5 kHz data cables
IEC 1000-4-4 Severity 3
10 Emitted interference Limit class A
EN 55011
11 Approvals
• UL
• CSA
• CE mark
• PROFIBUS certification
ð Underwriters Laboratories
ð Canadian Standards
Association
ð Certificate of conformity from
ð PROFIBUS user organization
12 Standards, specifications
• DIN 40050; IEC 529
• VDE 0106, protection class 3
• VDE 0160, where applicable
• VDE 0110 - insulator group IIIa, IIIb
- pollution severity 3
• IEC 68
• IEC 721-3-1/-3
• IEC 1131-2
• IEC 1000-4-2/-3/ -4/ -5/ -6
• EN 55011, DIN VDE 0875-11
• EN 50022
• EN 61131-2
• UL 508
• CSA 22.2-14
ð IP degrees of protection
ð Shock protection, protective
separation
ð Power installations
ð Insulation coordination
ð Env. conditions: Meas. methods
ð Env. conditions: Definitions
ð PLC interface standard
ð EMC requirements
ð EMC emissions
ð Standard DIN rail
ð PLC I/O modules
ð UL for indust. control systems
ð CSA for industrial equipment
13 Siemens standards
• SN 18013
• SN 18012
• SN 36350
• SN 31205
ð Packaging and drop test
ð Labeling of packaged items
ð Recycling guidelines
ð Environmental conditions
