Communication System Manual 3VF Circuit-Breakers
Version 1.0 (05/98) Copyright Siemens AG 1998. All rights reserved.
17
2.1.5 Selection and ordering data
The possible combinations for communication-capable 3VF circuit-breakers (40 kA, 415 V, 3-pole, fixed-
mounted) are listed with their order numbers in the table below. This will help you to quickly locate the
most economical solution for the specified bus functions based on the prepared order numbers. The
hardware and software required in addition to the circuit-breaker must be ordered separately.
Measuring Circuit-breaker, Motorized op. mech. SIMOCODE-DP
range release "an", for ON/OFF (230 V AC)
with HS and AS 220 - 240 V AC
25 - 100 A 3VF3 111-1BQ41-0AN1 3VF9 323-1ME10 3UF5021-3BN00-1
50 - 200 A 3VF3 311-1BX41-0AN1 3VF9 323-1ME10 3UF5031-3BN00-1
125 - 250 A 3VF4 211-1BM41-0AN1 3VF9 423-1ME10 3UF5041-3BN00-1
125 - 400 A 3VF5 211-1BM41-0AN1 3VF9 523-1ME10 3UF5041-3BN00-1
125 - 500 A 3VF6 211-1BK44-0AN1 3VF9 623-1ME10 3UF5041-3BN00-1
200 - 630 A 3VF6 211-1BM44-0AN1 3VF9 623-1ME10 3UF5051-3BN00-1
200 - 800 A 3VF7 111-1BK60-0AN1 3VF9 723-1NE30 3UF5051-3BN00-1
Note:
Standard circuit-breaker and SIMOCODE-DP devices are used for the purposes of the overview. These
can be controlled directly from SIMOCODE-DP in the case of motorized operating mechanisms with a
rated voltage of 230 V.
If control voltages < 230 V are required for motorized operating mechanisms, additional auxiliary
contactors (relays) must be used, as the relay contacts of SIMOCODE-DP (max. load rating 5 A)
can be overloaded or damaged due to the increased current input.
