Siemens 3VF Series User Manual

Communication System Manual 3VF Circuit-Breakers
 Copyright Siemens AG 1998. All rights reserved. Version1.0 (05/98)
20
Control Stations:
Inching mode = Off
Local ON 1 = Not connected
Local OFF = Basic unit, input 3
Local ON 2 = Basic unit, input 2
DP ON 1 = DP bit 0.0
DP OFF = DP bit 0.1
DP ON 2 = DP bit 0.2
Control and observe station ON1 = Not connected
Control and observe station OFF = Not connected
Control and observe station ON 2 = Not connected
Operator panel ON1 = Not connected
Operator panel OFF = Not connected
Operator panel ON 2 = Not connected
Control function ON1 = Group control station on 1
Control function OFF = Group control station off
Control function ON 2 = Group control station on 2
Changeover switch S1 = Not connected
Changeover switch S2 = Not connected
Operator Enabling:
Changeover switch S1 = Not connected
Changeover switch S2 = Not connected
Mode 1: S1=0, S=0
LOS-On = free
LOS-Off = free
DP-On = Disabled
DP-Off = Disabled
CaO-On = Disabled
CaO-Off = Disabled
OP-On = Disabled
OP-Off = Disabled
Mode 2: S1 = 0, S2 = 1
LOS-On = free
LOS-Off = free
DP-On = Disabled
DP-Off = Disabled
CaO-On = Disabled
CaO-Off = Disabled
OP-On = Disabled
OP-Off = Disabled
Mode 3: S1 = 1, S2 = 0
LOS-On = Disabled
LOS-Off = Disabled
DP-On = Disabled
DP-Off = Disabled
CaO-On = free
CaO-Off = free
OP-On = Disabled
OP-Off = Disabled
Mode 4: S1 = 1, S2 = 1
LOS-On = Disabled
LOS-Off = Disabled
DP-On = free
DP-Off = free
CaO-On = Disabled
CaO-Off = Disabled
OP-On = Disabled
OP-Off = Disabled
