Siemens 3VF Series

Communication System Manual 3VF Circuit-Breakers
 Copyright Siemens AG 1998. All rights reserved. Version1.0 (05/98)
24
Bus PROFIBUS-DP:
Reduced diagnostic message = No
Parameter block = Yes/No System-specific
Operating Mode = DP-V1
DP process data:
Format = Basic type 2
Byte 0:
Bit 0 = Basic unit, input 2 HS: 3VF "ON": DS 130 Par 28
Bit 1 = Basic unit, input 3 HS: 3VF "OFF": DS 130 Par 29
Bit 2 = Basic unit, input 4 AS: 3VF "Tripped": DS 130 Par 27
Bit 3 = Not connected
Bit 4 = Not connected
Bit 5 = Not connected
Bit 6 = Not connected
Bit 7 = Not connected
Byte 1:
Bit 0 = Not connected
Bit 1 = Not connected
Bit 2 = Not connected
Bit 3 = Not connected
Bit 4 = Not connected
Bit 5 = Ext. check-back signal 1 DS 130 Par 27
Bit 6 = Ext. check-back signal 2 DS 130 Par 28
Bit 7 = Ext. check-back signal 3 DS 130 Par 29
Hard-wired:
Byte 2/3: = Actual phase current as % DS 131 Par 7
Input delay:
Inputs basic unit = 18 ms
Inputs expansion module = 36 ms
LEGEND:
DS: Data set
Par: Parameter
HS: Auxiliary switch
AS: Alarm switch
