Communication System Manual 3WN6 Circuit-Breakers
56 Copyright Siemens AG 1998. All rights reserved. Version 1.0 (05/98)
Message group 1
T-Nr. Designation Message
address
Time response of communication
(Duration of read/write operations
1:x Circuit-breaker
functions
(See pages 41 - 51 for details)
and update rate for values in 3WN6)
x =
0 Switching actions 721, ... The switching actions are write-only. The maximum
time required for the PLC to write them to 3WN6 and
for the switching command to be executed is 600 ms.
1 Circuit-breaker state 741, ... The data in messages 1:1 to 1:5 are read-only.
2 "Tripped" signals 742, ... It takes approx. 530 ms for the PLC to read these
3 Warning signals 743, ... values out of 3WN6. The values are updated within
the circuit-breaker approx. every 700 ms.
5 Processor status 745, ...
8 Fault signals 748, ... As with messages 1:1 to 1:5, however the measured
(For comm. module with values in the circuit-breaker are updated every
measurement functions
only: Z=F05)
1000 ms.
11 - 51 Operational data 762 - 773 As with messages 1:1 to 1:5.
61 - 93
107,108
Setting values/
Protection parameters
(Z=F01 or Z=F05)
782 - 790 The data in messages 1:61 to 1:93, 107 and 108 are
(configurable as) read-write.
It takes approx. 530 ms to read these values and
from approx. 500 to a maximum of 1200 ms to write
them. After a write operation, the written value can
be called up after 200 ms (i.e. max. time for write +
check operations: 1200 + 200 + 510 = 1910 ms).
Values which have just been read are updated after
approx. 700 ms. Otherwise values are updated at
intervals of 5000 ms.
101 -
106
Setting values/
Protection parameters
(Z=F05)
The data in messages 1:101 to 1:106 are
(configurable as) read or read-write depending on
the release type.
It takes approx. 550 ms to read or write these values.
The values in 3WN6 are updated regularly.
111 -
112
Additional functions (1 and
2)
812, 820 The data in messages 1:111 and 1:112 are
(configurable as) read or read-write depending on
the release type.
It takes approx. 530 ms for the PLC to read these
values out of 3WN6 and from approx. 500 to a
maximum of 1200 ms to write them.
Values which have just been read are updated after
approx. 700 ms. Otherwise values are updated at
intervals of 5000 ms.
