Communication System Manual 3WN6 Circuit-Breakers
58 Copyright Siemens AG 1998. All rights reserved. Version 1.0 (05/98)
RELEASE
Time response of communication
(Duration of read/write operations
and update rate for values in 3WN6)
3WN6 output data (cyclic)
OCTET 9
Ready to close BIT 15 It takes approx. 150 ms to read cyclic data in
Load shedding BIT 14 the PLC I/O area of 3WN6. The cyclic data are
Reserved BIT 13 updated within 3WN6 approx. every 700ms.
Phase number for main actual value BIT 12
Phase number for main actual value BIT 11
Group error signal
55)
BIT 10
Group warning signal
53)
BIT 9
Group fault signal
53)
BIT 8
OCTET 10
BIT 7
"Tripped" signal not acknowledged BIT 6 as above
Electrical closing lockout BIT 5
BIT 4
Storage spring charged BIT 3
BIT 2
Circuit-breaker OFF BIT 1
Circuit-breaker ON BIT 0
OCTETS 11 and 12
Current in highest loaded phase as above
L
1
, L
2
or L
3
[A]
55)
The "group error signal" is set (= 1) of one bit of "processor status" (message 1:5, page 45) is set. Similarly, the "group warning signal" is set (= 1) of
one bit of "warning signals" (message 1:3, Seite 44) is set and "group fault signal" is set if one bit of "Tripped signals" (message 1:2, page 43) is set. An
additional option for releases N and P when used in conjunction with the communication module with measurement functions (Z=F05) is to apply the
"fault signals" (message 1:8, Page 46) to either the "group warning signal" (for OS1:2 = 0) or the "group fault signal" (for OS1:2 = 1) by means of
"additional functions 1" (message 1:121, Page 50).
