Communication System Manual 3WN6 Circuit-Breakers
Version 1.0 (05/98)  Copyright Siemens AG 1998. All rights reserved. 73
3.5.3.6.3 DBG0 (DB210)
DB210 C:BS3WN6ST.S5D LAE=261 /90
3WN6 ASSIGNMENT TO MESSAGE GROUP 0 Sheet 1
0: KY = 000,000;
1: KF = +00000;
2: KY = 000,000; 0:01 TEST UNIT+DELIVERY DATE
3: KF = -00248;
4: KY = 000,000; 0:02 IDENTIFIER NUMBER
5: KF = +00247;
6: KY = 000,000; 0:03 COMMUNICATION TYPE
7: KF = +00000;
8: KY = 022,000; 0:04 RATED CURRENT OF CIRCUIT-BREAKER
9: KF = +00630;
10: KY = 000,000; 0:05 FUNCTION TEST OF RELEASE
11: KF = +00000;
12: KY = 000,000; 0:06
13: KF = +00000;
14: KY = 000,000; 0:07
15: KF = +00000;
16: KY = 000,000; 0:08
17: KF = +00000;
18: KY = 000,000; 0:09
19: KF = +00000;
20: KY = 000,000; 0:10
21: KF = +00000;
22: KY = 000,000; 0:11 CIRCUIT-BREAKER SIZE
23: KF = +00247;
24: KY = 000,000; 0:12 CIRCUIT-BREAKER TYPE
25: KF = -02049;
26: KY = 000,000; 0:13 NO. OF POLES
27: KF = -00248;
28: KY = 000,000; 0:14 REVISION LEVEL OF RELEASE UNIT
29: KF = +00068;
30: KY = 000,000; 0:15 REVISION LEVEL OF COMMUNICATION
31: KF = +05121;
32: KY = 000,000; 0:16 VERSION OF RELEASE UNIT
33: KF = +00017;
34: KY = 000,000; 0:17
35: KF = +00000;
36: KY = 000,000; 0:18
37: KF = +00000;
38: KY = 000,000; 0:19
39: KF = +00000;
40: KY = 000,000; 0:20
41: KF = +00000;
42: KY = 000,000; 0:21 COMMUNICATION ADDRESS
43: KF = +00052;
The storage structure of the read results for message group 0 is already apparent here (circuit-breaker
data).
