Communication System Manual 3WN6 Circuit-Breakers
Version 1.0 (05/98) Copyright Siemens AG 1998. All rights reserved. 75
3.5.3.6.5 DBSZ (DB230)
DB230 C:BS3WN6ST.S5D LAE=261 /504
3WN6 ACTUAL VALUES MESSAGE GROUP 1 Sheet 1
0: KM = 00000000; 1:000 SWITCHING ACTIONS
1: KF = +00000;
2: KY = 160,068; 1:001 CIRCUIT-BREAKER STATE
3: KF = +00001;
4: KY = 000,001; 1:002 CIRCUIT-BREAKER FAULTS
5: KF = +00000;
6: KY = 000,000; 1:003 CIRCUIT-BREAKER WARNINGS
7: KF = +00000;
8: KY = 000,000; 1:004
9: KF = +00000;
10: KY = 000,000; 1:005 STATUS OF MEAS. MODULE
11: KF = +00000;
12: KY = 000,000; 1:006
13: KF = +00000;
14: KY = 000,000; 1:007
15: KF = +00000;
16: KY = 000,000; 1:008
17: KF = +00000;
18: KY = 000,000; 1:009
19: KF = +00000;
20: KY = 000,000; 1:010
21: KF = +00000;
22: KY = 022,000; 1:011 ACTUAL PHASE CURRENT L1
23: KF = +00000;
24: KY = 022,000; 1:012 ACTUAL PHASE CURRENT L2
25: KF = +00000;
26: KY = 022,000; 1:013 ACTUAL PHASE CURRENT L3
27: KF = +00000;
28: KY = 022,000; 1:014 MAX ACTUAL PHASE CURRENT
29: KF = +00000;
30: KY = 000,000; 1:015
31: KF = +00000;
32: KY = 022,000; 1:016 ACTUAL PHASE CURRENT N
33: KF = +00000;
34: KY = 022,000; 1:017 ACTUAL EARTH FAULT CURRENT I
35: KF = -00001;
36: KY = 000,000; 1:018
37: KF = +00000;
38: KY = 000,000; 1:019
39: KF = +00000;
40: KY = 000,000; 1:020
41: KF = +00000;
42: KY = 009,003; 1:021 ACTIVE POWER [AVERAGE]
43: KF = -01234;
44: KY = 010,003; 1:022 REACTIVE POWER [AVERAGE]
45: KF = -01408;
The parameter subindex of the T-Nr. is stored in DW T-Nr.*2.
The value which is to be parameterized or which has already been parameterized is stored in DW T-
Nr.*2+1. This depends on the comparison between the value read out and the content of this DB.
