Fail-Safe Modules
7.3 PM-E F pp DC24V PROFIsafe power module
ET 200S Distributed I/O System - Fail-Safe Modules
90 Installation and Operating Manual, 08/2008, A5E00103686-07
7.3.4 Parameters of the PM-E F pp DC24V PROFIsafe
Parameters in STEP 7
The table below lists the parameters that can be set for the PM-E F pp DC24V PROFIsafe.
Table 7- 8 Parameters of the PM-E F pp DC24V PROFIsafe
Parameter Range Default Type of
Parameter
Effective
Range
F-Parameters:
F_destination_address 1 to 1022 is assigned
by
STEP 7
Static Module
F monitoring time 10 to 10000 ms 150 ms Static Module
See also
Configuration and Parameter Assignment (Page 26)
7.3.5 Diagnostic functions of the PM-E F pp DC24V PROFIsafe
Behavior in Case of Supply Voltage Failure
The failure of the PM-E F pp DC24V PROFIsafe power supply is always indicated by the
PWR LED on the module (light off). This information is also provided in the module
(diagnostic entry). The relay output of the module is passivated.
In the case of a voltage dip in the external auxiliary voltage, the SF LED lights up, the
module is passivated.
With the subsequent supply recovery (level must remain above the specified value for at
least 1 minute (refer to the technical specifications: voltages, currents, electrical potentials))
the SF LED goes out again, the module remains passivated. The SF LED flashes if there are
no other errors, until the error is acknowledged.
