Technical data of CPU 31xC
6.6 Technical data of the integrated I/O
CPU 31xC and CPU 31x, Technical data
6-42 Manual, Edition 08/2004, A5E00105475-05
Parameters of standard AO
The table below gives you an overview of standard analog output parameters (see also
Chapter 4.3 in the
Module Data
Reference Manual).
Table 6-10 Parameters of standard AO
Parameters Value range Default Range of efficiency
Output range
(channel 0 to 1)
Disabled/
+/- 20 mA/
0 ... 20 mA/
4 ... 20 mA/
+/- 10 V/
0 ... 10 V
+/- 10 V Channel
Type of output
(channel 0 to 1)
Disabled/
V voltage/
I current
U voltage Channel
