Installing and connecting the device

3.2 Mounting the device

SIMATIC IOT2050

Operating Instructions, 03/2020, A5E39456816-AA

Fasten securely

NOTICE

Insufficient load carrying capacity

If the mounting surface for wall mounting does not have an enough load-bearing capacity,

the device may fall and be damaged.

Ensure that the mounting surface on the wall can bear four times the total weight of the

device, including fixing elements.

NOTICE

Incorrect fixing elements

If you use anchors and screws other than those specified below for wall mounting, safe

mounting is not guaranteed. The device can fall and may be damaged.

Only use the anchors and screws specified in the following table.

Material

Bore diameter

Fixing element

Concrete Select according to the speci-

fication of the mounting ele-

ments used

• Anchor, ∅ 6 mm, 40 mm long

• Screw, ∅ 4 mm, 40 mm long

Plasterboard,

(at least 13 mm thick)

Toggle plug, ∅ 12 mm, 50 mm

long

Metal,

(at least 2 mm thick)

• Screw M4 × 15

• M4 nut

3.2.2 Mounting on DIN rails

3.2.2.1 Secure the mounting clips

Requirement

● The DIN rail is installed at the installation site (35 mm standard profile).

● Mounting bracket and mounting clamps

● Two screws

● T8 screwdriver
