05.2005 Allacciamento
Siemens AG 6SE7087-2NP85-0AA0
SIMOVERT MASTERDRIVES Istruzioni di servizio 7-3
SIEMENS
X100
resistenza frenatura
uscita DC24 V,
RS485 (USS) X100
a
limentazione esterna DC24 V X9
Run
Failure
allacciamento rete X1
X6
uscita relé segnalazione X91
Chopper
active
LED segnalazione
supporto per Operation Panel
Operation Panel X320
sbarre circuito
intermedio
X3
PE3
−
+
HGPE
Fig. 7-2 Panoramica allacciamenti delle unità di alimentazione 50 kW / 100 kW
