[sc-cfc-statistic, 1, en_US]
Figure 8-3 CFC Statistics
NOTE
The fast-event-triggered CFC charts have the highest priority and are processed before all other tasks. At
this level, a considerable smaller number of ticks are available than at all other tasks. It is recommended to
configure only very-high-priority logic functions at this task and to configure the other logic functions in
any other level.
NOTE
Empty CFC charts also consume system resources. Empty charts that are not required any more should be
deleted.
Supervision Functions
8.2 Resource-Consumption Supervision
