Siemens 7KE85 - Current Phase-Rotation Supervision; Analog Channel Supervision Via Fast Current Sum

Current Phase-Rotation Supervision
Setting Values
Tripping delay 0.00 s to 100.00 s Increments of 0.01 s
Phase-rotation direction A B C
A C B
Times
Tripping time Approx. 500 ms
Dropout time Approx. 500 ms
Analog Channel Supervision via Fast Current Sum
Times
Pickup times Approx. 2 ms (faster than the fastest protection function)
Dropout time Approx. 100 ms
11.5.7
11.5.8
Technical Data
11.5 Supervision Functions
SIPROTEC 5, Fault Recorder, Manual 443
C53000-G5040-C018-5, Edition 11.2017
