A 01/13 2-channel Binary Signal Transducer Page 35 of 40
s
Page 34 of 40 2-channel Binary Signal Transducer A 01/13
s
Name Order No.
Binary signal transducer
7XV two-channel
2 binary inputs,
2 command inputs,
1 fault signal output via terminals
1.5 Ordering data
5 6 5 B03
Code
A
0 0
1.6 Installation and commissioning
Warning!
When operating electrical devices, certain parts of these devices are
necessarily under dangerous voltage. Therefore, disregard of the
operating notes may cause severe bodily injury or property damage.
Installation and electrical connection of the device should be performed
by adequately qualified personnel only.
In particular, all warnings must be strictly observed.
Do not look directly into the FO transmission diodes when
wearing optical aids !!!
Warning !
THE DEVICE MUST NOT BE OPERATED WHEN OPEN.
Warning !
