English 7XV5655-0BA00
24 / 53 C53000-G1176-C174-3
PC <–> Serial Hub LAN connection in an existing network
The Serial Hub is connected with a patch cable (not cross-over) to a hub or switch in an
existing network to which the operating PC/laptop is also connected. The PC usually
obtains a free IP address from the server.
The LAN connection of the operating PC to the network can be checked as described in the
previous section.
In the "Local area connection status" window,
go to
"General"
to display the status of the network
connection.
Here a connection has existed for 22 h 53min
at 100 Mbps.
Under
"Support"
you can look at the settings assigned to the
connection.
Here, the network addresses are
automatically assigned by a DHCP server in
the network.
After you have started the configuration tool, all Serial Hubs connected in the same network
segment are found automatically and can be configured (see Section "Configuration tool").
