9Getting started
VAR Language: English; VAR issue date: 08-August-2003
Using the SIM
card/battery
The service provider supplies you
with a SIM card on which all the
important data for your account is
stored. If the SIM card is credit card-
sized, snap out the smaller segment
and trim any rough edges.
• Remove the cover in the direction
of the arrow
1.
• Insert the SIM card in the opening
with the contact area facing down-
wards and push gently until it
engages below the holder (make
sure the angled corner is in the
correct position
2).
• Insert the battery sideways into
the phone
3, then press down-
wards
4 until it engages.
• To remove, press the retaining tab
5 then lift the battery out.
• Slide the cover over the phone
6
until it latches into place.
1
2
Additional notes
Always switch off phone before removing
the battery!
Only 3V SIM cards are supported. Please
contact your service provider if you have an
older card.
Functions without SIM card ...............p. 12
3
4
5
6
