4 Installation and Setting Instructions
ARCADIS Avantic SPR2-330.814.01.01.02 Siemens AG
02.05 CS SD 24
Page 4 of 10
Medical Solutions
2-
1Installation and Setting Instructions
General information 0
Safety instructions 0
NOTICE
To avoid light to severe, possibly fatal, injuries and material dam-
age:
¹ The product-specific safety information in the system
manual as well as the safety information in the ARTD,
part 2, must be observed.
¹ After all work has been completed and all covers have
been attached, perform the protective conductor test
according to ARTD-002.731.17. The protective conductor
resistance may not exceed 0.2 Ohms.
¹ Checks and settings that need to be performed under
X-ray radiation are identified by the radiation symbol
x . Radiation protective clothing must be worn while
performing procedures marked with this symbol.
Additional information 0
These instructions only apply to the retrofitting of the dose meter to an ARCADIS Avantic
system.
Required parts 0
Required measuring and auxiliary equipment 0
Required tools 0
• Tool case (see SPC catalog)
• DAP meter (including 4 threaded bolts) 10 04 76 54
• Dose meter e.g., PTW-Diados 97 17 612 Y0388
• Crosshair 96 60 051 RE999
