Mount and connect
3
Mount AV
S74 operator unit
33
Siemens Graphical User Interface UI400 CE1U2348en
Building Technologies 2014-06-03
l Place the unit from the rear on the housing cutout.
l Attach the unit to the source housing using 4 screws.
Screw on housing
