Test plant, diagnostics
74
Siemens Graphical User Interface UI400 CE1U2348en
Building Technologies 2014-06-03
8.1 Test plant, diagnostics
The following is displayed on the Diagnostics pages ( ):
1. Input/output test
2. Communication
3. Simulation
4. Producer
5. Consumers
6. Error history
7. Versions
A topic list is displayed in the work area when selecting diagnostics pages.
The entries can be individually selected. The actual diagnostics pages open.
The user's guide for the controller includes detailed information on the individual
diagnostic and test parameters.
Operating and use of diagnostic pages is illustrated below using the input/output
test as an example.
Structure
