84
Siemens Graphical User Interface UI400 CE1U2348en
Building Technologies 2014-06-03
9.2 AVS74
Power supply Via cable (with plug) from controller
Interfaces Bus. BSB-W,
Via cable (with plug)
Maximum wire length controller/operator
unit
1 m
USB Type Mini-B
Classification as per
EN 60730
Degree of pollution 2
Design type Safety class III (for proper installation)
Suitable for installation in equipment safety
class I and II
Housing Protection as per EN 60529
AVS74.261:
IP40
- Installed.
AVS74.661:
IP40
- Installed
AVS74.761:
IP44
- Installed.
- All housing parts mounted.
- Installation: Deviation from vertical ≤ 40°.
Air tightness As per EN 15502-2-1
AVS74.661 / AVS74.761:
Suitable for applications with leakage rate ≥ 0.4
m
3
/h at 0.5 mbar
Standards, guidelines Electromagnetic compatibility
(application range)
For residential, commercial, and industrial
environments.
EU conformity (CE) T7471x5
Climatic conditions Storage as per IEC60721-3-1 Class 1K3, temp. -20….65 °C
Transport as per IEC60721-3-2 Class 2K3, temp. -25….70 °C
Operation as per IEC60721-3-3 Class 3K5, temp. 0...60 °C (non-condensing)
Mechanical conditions Storage as per IEC60721-3-1 Class 1M2
Transport as per IEC60721-3-2 Class 2M2
Operation as per IEC60721-3-3 Class 3M2
Environmental compatibility
The product environmental declaration ()
contains data on environmentally
compatible product design and
assessments (RoHS compliance,
materials composition, packaging,
environmental benefit, disposal).
CE1E2348
Color Housing parts (no glass) RAL 9003 (signal white).
Dimensions Width x Height x Depth 144 x 96 x 26 (33.6 with control knob) mm
Weight Without/with packaging * AVS74.261: 219 / 276 g
AVS74.661: 214 / 271 g
AVS74.761: 221 / 278 g
* AVS74 devices are in multipacks.
As a share of packaging weight.
