PXL Conventional Fire Alarm Control Panel
Appendix D
72
PROGRAMMING
The Silent Knight Model 5230 LCD Keypad Programmer can be connected temporarily to Pin
P4 on the Silent Knight 5128 Main Board (See Figure 27) for on-site programming or trouble-
shooting of the communicator. English language messages assist in entering data, changing
the 24-hour test time, and describing conditions currently in effect.
Table 15 lists the recommended program for the Silent Knight 5128/5129 Digital Fire Commu-
nicator. Before you begin programming, read the Step Programming Form in the Silent
Knight Model 5128/5129 Fire Slave Communicator Installation Manual, August, 1994, P/N
150805, provided with the Silent Knight 5128/5129.
NOTES:
1. If the selection is left blank, the user must fill in the proper information.
2. Skip = No selection is required.
3. After each selection is made, press the ENTER key to proceed to the next step.
4. a. If the Silent Knight Model 5129 Digital Fire Communicator is used and independant
AC Fail is to be reported, enter a number from 6 to 15 hours; otherwise, enter 0.
Six hours is required for Central Station; 15 hours is required for Remote Sation.
b. If the Silent Knight Model 5128 Digital Fire Communicator is used, enter 0 hours.
5. The PXL must be programmed to delay the trouble relay on AC fail. Follow the steps
below:
a. Enter the Program mode.
b. From the Set Timers menu, select Set AC Fail Relay Delay to 6 hours for Central
Station applications or 15 hours for Remote Station applications.
No. Option Name Select
1 ZONE ACTIVE 0
2 ZONE SUPERVISED yes
3 ALARM CHANNEL INPUT 0
4 TROUBLE CHANNEL INPUT 0
5 SUPERVISORY CHANNEL 0
6 ZONE RESPONSE 1 0
7 ZONE RESPONSE 2 SKIP
See Note 2
8 ZONE RESPONSE 3 0
9 ZONE RESPONSE 4 0
10 RELAY 1 1
11 INSTALLERS CODE
12 OPERATORS CODE
13 DIALER TYPE 0
14 COMPUTER ENABLE yes
15 TOUCHTONE LINE 1 yes
16 TOUCHTONE LINE 2 yes
17 MUST REPORT 1 yes
18 MUST REPORT 2 yes
19 AC MONITORING 2
20 AC LOSS HOURS
See Note 4
No. Option Name Select
Step
21 RINGS SKIP
See Note 2
22 3/1 ALARM CODE
23 3/1 TROUBLE CODE
24 3/1 RESTORE CODE
25 3/1 TEST CODE
26 ALARM 1 FIRST yes
27 TROUBLE 1 FIRST yes
28 TEST 1 FIRST yes
29 ACCOUNT 1
30 ATTEMPTS 1 3
31 FORMAT 1
32 PHONE 1
33 ACCOUNT 2
34 ATTEMPTS 2 3
35 FORMAT 2
36 PHONE 2
37 COMPUTER ACCOUNT SKIP
See Note 2
38 COMPUTER PHONE SKIP
See Note 2
39 TEST TIME
40 CURRENT TIME
Step
Table 15
Silent Knight Model 5128/5129 Programming Table
