Configuration
3.4 Other options when configuring a CP 243-1
CP 243-1
Operating Instructions, 03/2012, C79000-G8976-C244-02
87
Parameter Description Example
User name Valid user name on the addressed FTP
server
Written in plain text and consisting of 1
to 32 characters
00|R|23|VB11|/flash:/dat/CPU10_VB11
_23.dat| 192.168.162.65|FTP_server_4|
<password>
The file
/flash:/dat/CPU10_VB11_23.dat is
transferred from the file system of the
FTP server obtainable with the IP
192.168.162.65 (stating user_name
FTP_server_4 and <password>) to the
CP 243-1. There, 23 bytes from the file
are written to the DB of the CPU
starting at address VB11.
Password The password belonging to the
specified user name
Is encrypted and stored with a
character length of up to 64 characters.
The actual password length is between
1 and 32 characters.
00|R|23|VB11|/flash:/dat/CPU10_VB11
_23.dat|
192.168.162.65|FTP_server_4|W9vQ}G
cfH
The file
/flash:/dat/CPU10_VB11_23.dat is
transferred from the file system of the
FTP server obtainable with the IP
192.168.162.65 (stating user_name
FTP_server_4 and password
!state_Cp1) to the CP 243-1. There, 23
bytes from the file are written to the DB
of the CPU starting at address VB11.
Example of an FTP client configuration file
# This is a comment
TIMESTAMP=3D2C4E48
FILETYPE=FDB
FILEFORMAT=01
00|W|1|VB0|station99_VB0_1.dump|192.168.232.13|FTP_server_2|3AqW&4Cv
01|W|1024|VB256|/station36_VB256_1024.data|192.168.232.13|FTP_server
_2|3AqW&4Cv
02|R|5|VB2|/data/station36_VB2_5.err|192.168.232.2|FTP_server_3|asw3
45Df
03|R|23|VB11|/flash:/dat/CPU10_VB11_23.dat|192.168.162.65|
FTP_server_4| W9vQ}G cfH
04|||||||
05|||||||
06|||||||
07|D|||/data/station36_VB2_5.err|192.168.232.2|FTP_server_3|asw345Df
08|||||||
.....
30|||||||
31|||||||
END
# End of File
