Programming
4.3 ETHx_XFR
CP 243-1
Operating Instructions, 03/2012, C79000-G8976-C244-02
97
Return parameters
Name Type Meaning
Done BOOL Status of the subroutine call
0: Subroutine not executed yet
1: Subroutine executed, ready for next
execution
Error BYTE Error code
16#00: No error occurred
Otherwise: Error (description: see
section Error messages of the CP 243-
1 (Page 108))
Return parameters (ETHx_CFG)
4.3 ETHx_XFR
Calling the subroutine ETHx_XFR causes the CP 243-1 to transfer data to or request data
from another S7 system. The type of data access that your CP 243-1 uses is specified in the
configuration. This means that you have already specified the following during configuration:
What data is to be accessed.
Whether the data is to be read or written.
The communications partner from which this data is obtained or to which this data is
transferred.
When you call the ETHx_XFR subroutine, you specify which of the configured client
channels you want to use for which configured data accesses.
The ETHx_XFR subroutine is only created by the Internet wizard in STEP 7 Micro/WIN 32 if
you have configured at least one of the channels of the CP 243-1 as client. Only then can
you trigger data access from a S7-200 user program via a CP 243-1.
Only one ETHx_XFR subroutine per channel can be active at any one time. Parallel
execution of several data accesses to one channel is impossible. As a result, it is advisable
to link the "START" input with both the return value "Done" of the ETHx_XFR subroutine and
the corresponding bit of the return value "CH_Ready" from the ETHx_CTRL subroutine.
