Siemens CP 243-1 - Error messages in byte format

Diagnostics
5.2 Error messages of the CP 243-1
CP 243-1
110 Operating Instructions, 03/2012, C79000-G8976-C244-02
5.2.1 Error messages in byte format
Error byte Description Reaction/remedy Transfer mechanism
hex dec Byte offset in the
SM area
Return value
(ETHx_)
16#01 1 Timeout on the S7 bus Automatic restart 25 - 32
33
34
35
_XFR
_CFG
_EMAIL
_FTPC
16#02 2 Data access terminated due
to an ABORT command
A new read/write
request can be started
25 - 32
34
35
_XFR
_EMAIL
_FTPC
16#03 3 The transfer parameter
DATA or MAIL or OP is
outside the configured area
Check user program or
configuration
25 - 32
34
35
_XFR
_EMAIL
_FTPC
16#04 4 The connection could not be
set up at the S7 level
The attempt to
establish a connection
is repeated
25 - 32 _XFR
The connection was aborted
or an attempt was made to
execute a read/write
request on a channel that
was not ready
Check connection path
to the communications
partner or configuration
of the communications
partner
25 - 32 _XFR
The connection could not be
established or was aborted
or the e-mail configuration
file on the CP 243-1 was
changed or an attempt was
made to execute a request
and the parameter
assignment for the e-mail
service was not correct.
Check connector of
connection to the
communications
partner
Check .edb file on the
CP 243-1 for
uniqueness and
completeness
34 _EMAIL
The connection could not be
established or was aborted
or the FTP configuration file
on the CP 243-1 was
changed or an attempt was
made to execute a request
and the parameter
assignment of the FTP
client service was not
correct.
Check connector of
connection to the
communications
partner
Check .fdb file on the
CP 243-1 for
uniqueness and
completeness
35 _FTPC
16#05 5
The FTP connection was
aborted
Check connection path
to the communications
partner
Check FTP server
configuration for
completeness
36
