Hardware installation
3.3 Hardware compatibility
CP 5623/CP 5624
Operating Instructions, 09/2013, C79000-G8976-C281-03
19
The CP 5624 can replace the following predecessor versions:
● CP 5613 A3 and CP 5614 A3
● CP 5613 A2 and CP 5614 A2
● CP 5613 and CP 5614
Note
PCI Express
Please note: The CPs of the 5613 / 5614 series are PCI cards. The CP 5623 and CP 5624
communications processors are PCI Express cards. This means that you can only replace
previous versions with a CP 5623 / CP 5624 if there is a free PCI Express slot avail
able in
Note
No configuration changes necessary
You can adopt the configuration of the previous CP. To do this, you simply need to reload
the configuration.
Procedure for replacement
When replacing a module, follow the steps described in the section "Hardware installation
(Page 17)".
