CP 5623/CP 5624
Operating Instructions, 09/2013, C79000-G8976-C281-03
23
Technical specifications
5
Technical specifications of the CP 5623 / CP 5624
Connection to PROFIBUS
Amount
• For CP 5623
• For CP 5624
1
2
Transmission speeds 9.6 kbps, 19.2 kbps, 45.45 kbps,
93.75 kbps, 187.5 kbps, 500 kbps,
1.5 Mbps, 3 Mbps, 6 Mbps, 12 Mbps
Design 9-pin D-sub female connector with screw
locking mechanism
RS-485 (ungrounded within the SELV
limits)
Properties Grounded cable shield
Floating interface signals
Connection to PG/PC
PCI Express x1
V 1.0a plug and play
Can also be operated in x4, x8 or x16.
Electrical specifications of the PCI plug-in connector
Operating voltage Rated voltage 3.3 VDC and 12 VDC
Permitted range DC 3.0 to 3.6 V for 3.3 VDC
11.0...13.0 VDC for 12 VDC
Properties Safety extra low voltage (SELV) to EN
60950
Current consumption Typical
• CP 5623
• CP 5624
720 mA at 3.3 V and 250 mA at 12 V
750 mA at 3.3 V and 300 mA at 12 V
Effective power loss Typical
• CP 5623
• CP 5624
5.4 W
6.1 W
Permitted ambient conditions
Operating conditions Temperature
(EN 60068-2-1+2)
Temperature change max.
+5...+60 °C
≤10 K/h
Rel. humidity
(EN 60068-2-78)
≤ 85% at 30 °C no condensation
