Description
2
The distributed inverter box
The distributed inverter box can be ordered with Article No. C-200269683.
The distributed inverter box has the following main components:
● Control cabinet for distributed mounting in the plant
● SINAMICS G120 inverter for controlling a motor
Article No.'s. 6SL3246-0BA22-1FA0 (CU250S-2 Control Unit) and 6SL3225-0BE32-2AA0
(PM250 Power Module)
● X202-2P IRT SCALANCE type switch for connection to PROFINET
Article No. 6GK5 202-2BH00-2BA3
● Brake rectifier made by Murr Elektronik
Intermittent duty
The distributed inverter box is designed for S3 intermittent periodic duty.
Technical specifications (Page 23)
More information about the components
You can find more information about the components of the distributed inverter box in the
Internet:
CU250S-2 operating instructions (https://support.industry.siemens.com/cs/ww/en/view/
109482997)
Hardware installation manual for PM250 Power Modules (https://
support.industry.siemens.com/cs/en/en/view/64875934)
Scalance X202-2P IRT (https://support.industry.siemens.com/cs/en/en/view/102051962)
Murr Elektronik Brake rectifier (http://shop.murrelektronik.com/en/SAP-Import-Shop-1/
ACTIVE-BRAKE-RECTIFIER-V-0-2-50001.html?listtype=search&searchparam=ACTIVE
%20BRAKE%20RECTIFIER%20V%200.2&src=search&srchPage=1&perPage=10&pos=1)
Distributed inverter box
Manual, 06/2018, A5E43491109B AB 7
