Siemens RDF301, RDF301.50..., RDF600KN, RDF600KN/VB, RDF600KN/S CE1N3171en
Smart Infrastructure Semi flush-mount communicating room thermostats 2020-02-21
Applications for heat pump systems
Application and output signal, DIP switches, diagram
· 1-stage compressor ON/OFF
(heating or cooling)
1
ON
2 3
· 1-stage compressor with electric
heater (heating or cooling)
ON/OFF
1
ON
2 3
3181S31
N1
T
B1
T
D3
3181S32
N1
T
YE
B1
T
D3
· 1-stage compressor ON/OFF
(heating and cooling)
1
ON
2 3
3181S35
N1
T
B1
T
D3
N1 Thermostat B1 Return air temperature sensor or external
room temperature sensor (optional)
YE Electric heater D3 Dewpiont sensor
Legend

Siemens DF301 Specifications

General

Brand	Siemens
Model	DF301
Category	Thermostat
Language	English
