Introduction
16 Unrestricted SICAM A8000 Series, SICAM I/O Modules
DC8-012-2.06, Edition 09.2019
1.1 Overview
1.1.1 Application
The SICAM I/O modules are used for external expansion of the SICAM A8000 Series with
additional in- and outputs.
The SICAM A8000 Series is suitable for electrical distribution substations, gas distribution
substations, hydropower plants, pipelines and railway power supplies.
The SICAM I/O modules are used in the peripheral element of the SICAM A8000 Series from
the SICAM RTUs system family.
Peripheral Element Designation
CP-8000/USIO81 Universal Signal Input / Output
CP-8021/USIO81 Universal Signal Input / Output
CP-8022/USIO81 Universal Signal Input / Output
1.1.2 I/O Modules
I/O Module Designation Article number
DI-8110 Binary Input 2x8, DC 24 V 6MF28110AA00
DI-8111 Binary Input 2x8, DC 48/60 V 6MF28111AA00
DI-8112 Binary Input 2x8, DC 110 V 6MF28112AA00
DI-8113 Binary Input 2x8, DC 220 V 6MF28113AA00
DO-8212 Binary Output Relays 8x DC 24 to 220 V/AC 230 V 6MF28212AA00
AI-8310 Analog Input 2x2 Pt100/Pt1000 6MF28310AA00
AI-8320 Analog Input 4x ±20 mA/±10 V 6MF28320AA00
AI-8510 Analog Input 3x U (240 V), 3x I (LoPo) 6MF28510AA00
AI-8511 Analog Input 3x U (LoPo), 3x I (LoPo) 6MF28511AA00
AO-8380 Analog Output 4x ±20 mA/±10 V 6MF28380AA00
1.1.2.1 Accessories
I/O Module Designation Article number
CM-8811 Coupling Module SICAM I/O Modules
(only for CP-8000)
6MF28811AA00
CM-8812 Bus Connector SICAM I/O 10 pcs. (spare part) C53207-A5812-D481
CM-8820 CT-Adapter 3x I 1 A_5 A/225 mV 6MF28820AA00
