Standard I/O Modules
34 Unrestricted SICAM A8000 Series, SICAM I/O Modules
DC8-012-2.06, Edition 09.2019
2.4 DI-8113
2.4.1 Features
Binary input module
• Mounting on DIN rail
• 16 inputs (2 groups of 8 each)
• Galvanic insulation by optocouplers
• Each group has a common return
• Signal voltage DC 220 V
• Removable screw terminals
• Indication of function via LED
• Acquisition with a resolution of 1 ms
2.4.2 View
S IC AM A8 00 0
DI-8113
X2
X1
