1.2 Mechanical Design
1.2.1 System SICAM A8000 CP-8000
A SICAM CP-8000 system can be expanded by means of the coupling module CM-8811 with
up to 6 external I/O modules. The modules are mounted on a TS35 rail (DIN rail).
1.2.2 System SICAM A8000 CP-802x
A SICAM CP-802x system can be expanded with up to 8 I/O modules. The modules are
mounted on a TS35 rail (DIN rail).
F4
F3F2F1
POK
RY
ER
ETH
LK1
PK1
RS-232
OH2
RS-485
OH3
ETH
LK4
PK4
SD
X4
CP-8000
max. 6 I/O modules
TS35 rail
Coupling module
CP-8021
max. 8 I/O modules
TS35 rail
