Standard I/O Modules
40 Unrestricted SICAM A8000 Series, SICAM I/O Modules
DC8-012-2.06, Edition 09.2019
Mechanics and Connectors
Terminals Removable screw terminals (grid size 5.08)
Rated impulse voltage
4 kV < 2000 m: category III
< 3000 m: category II
2)
Connection data X1, X2, X3, X4
Locking torque
3)
(PHOENIX)
(FCI)
0.5 Nm to 0.6 Nm
0.36 Nm to 0.44 Nm
AWG
min. 22
max. 12
Conductor cross section solid
min. 0.33 mm²
max. 2.5 mm²
Conductor cross section stranded
min. 0.33 mm²
max. 2.5 mm²
Conductor cross section stranded with
ferrule without plastic sleeve
min. 0.33 mm²
max. 2.5 mm²
Conductor cross section stranded with
ferrule with plastic sleeve
min. 0.33 mm²
max. 2.5 mm²
2 wires stranded with ferrule without
plastic sleeve
min. 0.33 mm²
max. 1 mm²
2 wires stranded with TWIN ferrule with
plastic sleeve
min. 0.5 mm²
max. 1.31 mm²
Wire strip length
min. 6 mm
max. 7 mm
Length ferrule 10 mm
Dimensions 124 x 30 x 132 mm (L x W x H, dimensions w/o DIN rail)
Weight Approx. 287 g (incl. bus module 12 g)
1)
with parallel connection
2)
category III - ONLY when connecting identical external voltage levels for each load on each contact
of the groups X1 & X2 and X3 & X4 respectively
3)
the respective manufacturer is imprinted at the terminal (see section 1.2.4.1, Screw Terminal Types)
For power augmentation 2 relays may be connected parallel, this must happen within one group
(applies only for I < 6 A → 2 x 3 A)
Siemens recommends that outputs which are more
heavily loaded should not be adjacent to each other.
As a result, the stress on the device is distributed more evenly
DO-8212 is operated shall be considered applicable for all devices in the system.
